This array of IR LED/phototransistor pairs is great for precisely identifying changes in reflectance (like line detection). It operates from 2.9 V to 5.5 V and offers dimmable brightness control independent of the supply voltage. In general, the closer the object, the higher the contrast between light and dark readings, but high-reflectance objects are generally detectable out to around 30 mm. This version features high-performance, low-current QTRX sensors with lenses.
| pitch × sensors | size (mm) |
output | max current | optimal range |
|
|---|---|---|---|---|---|
| LED | board | ||||
| 8 mm × 2 | 13.0 × 20.0 | RC (digital) | 3.5 mA | 5 mA | 10 mm |
For further technical information, please see the main product page here
