950D61 RE 385 Metal Geared Motor 6:1

£14.83
(£17.80 UK, incl VAT)
Price in points: 2966 points
1450-101
144 g
In Stock
+ −
Add to wish list

MFA Como Drills 950D61

Output rpm at:

4.5V = 787
6V = 1050
9V = 1575
12V = 2100
15V = 2625
Output theoretical torque (g/cm) at 12V, max efficiency = 392, stall torque 2506



1450-100 to 106 Motor Performance (Note: 1450-107 to 113 Similar)
Nominal Voltage Current (A) Torque (g/cm) Speed (rpm) Efficiency (%) O/P Power (W)
12 0.155 0 11000   No Load
12 0.837 65.3 9821 61.85 max 6.21
12   417.6 Stall 0   0
