919D1001 RE 540/1 Metal Geared Motor 100:1

£15.12
(£18.14 UK, incl VAT)
Price in points: 3024 points
1450-057
290 g
In Stock
+ −
Add to wish list

MFA Como Drills 919D1001

Output @ 4.5V 59rpm
Output @ 6V 79rpm, 11820g/cm at max efficiency, stall torque 67000g/cm
Output @ 9V 119rpm
Output @ 12V 158rpm 15440g/cm at max efficiency, stall torque 100000g/cm
Output @ 15V 198rpm
Figures are theoretical for motor and gearbox combination

See 'Which Wheels' tab for suitable wheels type 6T for a tight fit. As an alternative, use 6mm gear adaptor 4607-062 or mounting hub 4609-106 with suitable wheels of your choice.
